PVC Shrink Sleeves Seaming Machine (Gluing Machine)

Send Inquiry

Request To Call Back

PVC Shrink Sleeves Seaming Machine (Gluing Machine)

Name: PVC Shrink Sleeves Seaming Machine (Gluing Machine)
Brand: S G Edge
Price: 400000 INR
Availability: InStock

Price 400000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

PVC Shrink Sleeves Seaming Machine (Gluing Machine) Specification

Torque
N/A (not applicable for this machine)

Phase
Single Phase

Shape
Rectangular body, film guided in roll form

Diameter
For film roll diameter up to 450 mm

Product Type
PVC Shrink Sleeves Seaming Machine (Gluing Machine)

General Use
For seaming and gluing PVC shrink film into continuous sleeves for shrink labels

Material
Mild Steel (MS) body with stainless steel working parts

Type
Other

Capacity
30-80 meters/minute (depends on operator skill and material)

Weight (kg)
Approx. 300 kg

Computerized
No

Touch Screen
No

Control System
Panel based

Surface Treatment
Powder coated / painted finish

QC System
Manual visual inspection

Tolerance
0.5 mm

Voltage
220 V / 50 Hz single phase

Dimension (L*W*H)
Approx. 1800 x 900 x 1200 mm

Feature
High speed; Adjustable guides for precise seaming; Easy operation; Low maintenance

Color
Industrial blue/grey (may vary as per manufacturer)

In-feed System
Manual with guided alignment

Power Consumption
Approx. 1.5 kW

Accessories
Glue tank, cleaning tools, toolkit

Applicable Film
PVC, PET-G (optional special setup)

Operating Temperature
Ambient; glue requires room temperature

Out-feed System
Tray/roller collection

Min. Film Thickness
25-80 microns

Max. Sleeve Width
300 mm

Speed Adjustment
Stepless electronic controller

Roll Core Size
3 inch standard

Noise Level
< 80 dB(A)

Seaming Method
Solvent-based glue application

Drive System
AC motor with variable frequency drive

PVC Shrink Sleeves Seaming Machine (Gluing Machine) Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
30 Days

Main Domestic Market
All India

About PVC Shrink Sleeves Seaming Machine (Gluing Machine)

The hot-selling PVC Shrink Sleeves Seaming Machine is a trending, pivotal solution for manufacturers seeking radiant efficiency and praiseworthy results in shrink label production. Designed for versatility, this customizable gluing machine accommodates film thicknesses of 25-80 microns and widths up to 300 mm. Featuring solvent-based glue seaming, an AC motor with variable drive, and stepless electronic speed adjustment (30-80 meters/min), it delivers consistent high-precision seams with minimal maintenance. With sturdy mild steel construction and stainless steel working parts, it ensures reliability and longevity for demanding industrial applications. Semi-automatic and panel-controlled, it's an indispensable choice for India's manufacturers, suppliers, and traders.

Application Areas & Special Features of the PVC Shrink Sleeves Seaming Machine

Ideal for high-throughput packaging operations, this machine finds wide application in industries producing PVC shrink sleeves, bottle labels, and packaging wraps. Suitable for processing both PVC and PET-G films (with optional setup), the unit ensures precise seams with its adjustable guides. Standout features include a praiseworthy powder-coated finish, radiant stainless steel working surfaces, high-speed output, and a manual guided in-feed system that enhances operational accuracy and efficiency.

Packaging, Supply, and Certifications - Delivered with Care

Each PVC Shrink Sleeves Seaming Machine is meticulously delivered with a comprehensive toolkit, glue tank, and cleaning utensils for immediate operation. Available at a competitive list price with options for the lowest price based on quantity, supply ability extends to large orders across India. While standard certification details vary by manufacturer, the machine is built to meet prevailing industry standards, supporting reliability and customer assurance throughout every deployment.

FAQ's of PVC Shrink Sleeves Seaming Machine (Gluing Machine):

Q: How does the PVC Shrink Sleeves Seaming Machine operate?

A: The machine operates by manually feeding PVC or PET-G film into the guided in-feed system, which aligns the material for precise solvent-based glue application. The AC motor with variable frequency drive allows for adjustable speed via a stepless electronic controller, ensuring consistent seam quality.

Q: What benefits does the seaming machine offer to manufacturers?

A: This seaming machine provides pivotal benefits such as high-speed performance, enhanced seam accuracy with adjustable guides, user-friendly panel control, low maintenance needs, and robust construction suitable for continuous industrial use.

Q: Where can the PVC Shrink Sleeves Seaming Machine be applied?

A: It's broadly used in packaging industries for making shrink sleeves and labels for bottles, jars, and consumer goods. Its adaptability to various film types and sizes makes it ideal for medium-to-large manufacturers and traders.

Q: What is the recommended film type for this machine?

A: The standard applicable film is PVC, with options for PET-G using a special setup. The machine handles film thicknesses between 25 and 80 microns and a maximum sleeve width of 300 mm.

Q: What is the process for cleaning and maintaining the machine?

A: The machine comes equipped with cleaning tools and a toolkit. Routine maintenance involves post-operation cleaning of the glue tank and working parts, along with periodic inspection, ensured by the manual visual QC system.

Q: When can I expect delivery and what packaging is provided?

A: Delivery timelines depend on the order size and arrangement with the supplier. The machine is delivered securely packed with all essential accessories, including a glue tank and tool kit, ensuring safe transit and immediate readiness for installation.
